IDC 4-Pin Shielded Cable Assembly – Custom OEM Interconnect

IDC 4-Pin Shielded Cable Assembly
– Custom OEM Interconnect



IDC 4-Pin Shielded Cable Assembly:

This IDC 4-Pin Shielded Cable Assembly is a custom OEM interconnect designed for
industrial and control applications requiring stable low-voltage signal transmission and
mechanical reliability.

The assembly features 4-position IDC female and male connectors (models 3-647002-4
and 3-640442-4) terminated on a LIYCY 4-core shielded cable with aluminum Mylar foil
and braided shielding.
Heat-shrink tubing and controlled strain-relief zones ensure durability in fixed or
semi-dynamic installations.

Cable length, pin assignment, wire colors, and labeling are fully customizable according
to customer drawings and system requirements.

IDC 4-Pin Shielded Cable Assembly – Key Features:

4-Position IDC Connector Interface
Compact IDC termination for reliable insulation displacement contact.

Female to Male Configuration
Designed for direct board-to-board or module-to-module interconnection.

Shielded Multi-Core Cable Structure
Aluminum Mylar foil + braided shield reduce EMI and external noise.

26 AWG Tinned Copper Conductors
Stable electrical performance with consistent crimp quality.

Heat-Shrink Reinforced Ends
Improved strain relief and long-term mechanical protection.

Custom OEM Manufacturing
Built strictly to customer drawings, pinouts, and test requirements.

IDC 4-Pin Shielded Cable Assembly – Typical Applications:

Industrial control systems

Sensor and actuator wiring

Embedded electronic modules

Automation and instrumentation equipment

Custom low-voltage signal harnesses

IDC 4-Pin Shielded Cable Assembly – Technical Specifications:

IDC 4-Pin Shielded Cable Assembly – Customization Options:

Cable length and jacket material

Connector gender and orientation

Pin assignment and wire color sequence

Shielding structure (foil / braid / combined)

Heat-shrink length and labeling content

Packaging and serialization

Engineering support is available from sample build to mass production.
